Insulated Wire End Sleeve 4.0 mm² HAE4, grey (100 pcs.)
Insulated Wire End Sleeve 4.0 mm² HAE4, grey (100 pcs.)

Insulated Wire End Sleeve 4.0 mm² HAE4, grey (100 pcs.)

  • Conductor cross section: 4.0 mm²
  • Pin lenght: 10 mm
  • Surface galvanised
  • Temperature resistance -60 °C to +105 °C

Item no. 002181

8,22 EUR

VAT incl.

Become a sales partner
Request an offer

Insulated Wire End Sleeve 4.0 mm2 HAE4, gray (100 pcs.)

For easy attachment to fine stranded copper conductors,
prevents fanning and damage to conductors.

The main characteristics
  • Conforms to DIN 46228, part 4
  • Material: Cu-ETP according to DIN EN 13600
  • Surface: galvanised
  • PP insulation (polypropylene)
  • Temperature resistance: -60 °C to +105 °C

Delivery content
  • Insulated Wire End Sleeve 4.0 mm2 HAE4 (Packing unit 100 pcs.)

Technical Data

Cross section 4.0 mm2
Pin length 10 mm
Surface Galvanised
Insulation Polypropylen
Temperature range -60 °C to +105 °C
DIN-Norm DIN 46228
Material Cu-ETP according to DIN EN 13600
Colour    Gray
Weight 40 g/100 pcs.
