Phaesun® Energy Generation Kit Solar Up One 50 W, 12 V

Island solar systems – Complete solution for self-sufficient power supply for garden houses, fishing huts, mobile chicken coops, etc.

Stand-alone solar systems convert sunlight into electricity.

The electricity generated is stored in a battery so that consumers such as refrigerators, pond pumps and lighting always have sufficient energy available.

The classic components of an off-grid solar system consist of one or more solar modules, solar charge controller, battery and voltage converter.

An inverter enables the connection of 230 V consumers to the 12/24 V battery. This creates a self-sufficient and environmentally friendly power supply away from the mains.

These integrated set allow an easy operation of 12 V DC consumers such as light, radio, or 12 V pond pumps etc. If you connect a 230 V AC inverter, you can also supply any electrical device just as if you were on the grid.

This set is an ideal solution if you need solar power only in the evening hours or weekends, e.g. for your garage, garden or holiday home.

Delivery content

• 2 x Solar module 50 W/12 V
• Solar charge controller 6 A, 12/24 V
• Module connection cable 10 m
• Battery cable with 15 A fuse

Suitable battery and inverter on request.

Technical Data

Solar module
System voltage	12 V DC
Power	50 W
Voltage (max.)	17.6 V
Current (max.)	2.84 A
Open circuit voltage	21.6 V
Short circuit voltage	3.07 A
Number of cells	36 x mono
Module type	Monocrystalline
Solar charge controller
Type	PWM
System voltage	12/24 V
Module voltage	12 V: 6.9 V - 17.2 V 24 V: 17.3 V - 43 V
Module power (max.)	300 Wp
Load current (max.)	10 A
Module current (max.)	10 A
Power consumption active	12.5 mA
Battery type	Lead Acid, Lead Gel, Lead AGM, LiFePO4
Weight	Set complete: 5.5 kg

---
